Protec Distribution Inc.
Building Products Listing Program
- Protec Distribution Inc.
- Plumbing Fixtures
- Quebec, QC
- P380
- P380 Ed 1
- January 21, 2023
- N/A
- N/A
-
ASTM A182/A182M-21 – Standard Specification for Forged or Rolled Alloy and Stainless-Steel Pipe Flanges, Forged Fittings, and Valves and Parts for High Temperature Service
-
Drag’eau Sludge Eliminator Products
-
Products are marked in a permanent manner where it is readily visible after installation with the following:
a) Manufacturer’s name or trademark
b) Model number or model designation
c) Date of manufacture
d) QAI file number: P380
e) The standard “ASTM A182/A182M-1”
f) QAI logo shown here:
-
Table 1, ASTM A182/A182M-1 Fittings
MODEL No.1 Nominal Connection
Size 3
(mm/(in))Diameter
(mm)Length (mm) Rated Flow
(lpm)2DS-I25 25 (1.0) 60 119 73 DS-I32 32 (1.25) 68 145 95 DS-I40 40 (1.5) 85 160 158 DS-I50 50 (2.0) 95 170 292 DS-I65 65 (2.5) 110 255 483 DS-I80 80 (3.0) 130 280 697 Note 1: These fittings were evaluated for compliance with ASTM A182/A182M, no evaluation was conducted on the fittings ability to ”Eliminate Sludge”
Note 2: this rating is based on the manufacturers claim.
Note 3: All fittings are rated by the manufacturer for a temperature of -20C to 155C and a maximum of 1500 kpa (217 psi)
The materials, products or systems listed in this directory have been qualified to bear the QAI Listing Mark under the conditions stated with each Listing. Only those products bearing the QAI Listing Mark are considered to be listed by QAI.
The standard herein listed is the currently accepted version within the relevant certification scheme, code or other requirements unless otherwise noted. Transition periods may apply. Upon request, QAI will provide information about the validity of any of its certifications.
No warrantee is expressed or implied, and no guarantee is provided that any jurisdictional authority will accept the Listing found herein. The appropriate authorities should be contacted regarding the acceptability of any given Listing.
Visit the QAI Online Listing Directory located at www.qai.org for the most up to date version of this Listing and to validate that this QAI Listing is active. Questions regarding this listing may be directed to info@qai.org. Please include the listing number in the request.
